Maximize Your Connectivity with Linksys X3000 Wireless-N ADSL2+ Modem Router
Elevate your network with the Linksys X3000 Wireless-N ADSL2+ Modem Router. Experience high-speed connectivity, versatile setup options for cable modem and DSL, and robust security features. Explore the product specifications for an in-depth look at its electrical and mechanical capabilities. Upgrade your home network with Linksys today!
Upgrade your home network with the Linksys X3000 Wireless-N ADSL2+ Modem Router, a high-speed ADSL gateway designed for versatile connectivity with both cable modems and DSL connections.
Product Features:
- Standards: WLAN – 802.11n, 802.11g, 802.11b; Ethernet – 802.3, 802.3u, 802.3ab; ADSL – T1.413i2, G.992.1 (G.DMT), G.992.2 (G.Lite), G.992.3 (ADSL2), G.992.5 (ADSL2+) for Annex A, B, M, L, U-R2 for Annex B; USB 2.0
- Ports: DSL, Cable, Gigabit (10/100/1000), Ethernet (1-4), Power, USB
- Buttons: On/Off, Reset, Wi-Fi Protected Setup™
- LEDs: Power, Ethernet (1-4), Wi-Fi Protected Setup™, Wireless, Internet
- Cabling Type: CAT5, RJ-11 (for Annex A), RJ-45 (for Annex B)
- Antennas: 2 Internal
- Security Features: WPA2™/WPA™ Personal and Enterprise, 128 and 64 bits WEP, MAC Address Filtering, SPI Firewall
The Linksys X3000 is compatible with USB devices that run under version 2.0. It can recognize FAT32, NTFS, and HFS+ formats.
Product Specifications:
- Electrical Modulations:
- 802.11b: CCK/QPSK, BPSK
- 802.11g: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
- 802.11n: OFDM/BPSK, QPSK, 16-QAM, 64-QAM
- Transmit Power:
- 802.11b: 12.5 ± 1.5 dBm
- 802.11g: 12.5 ± 1.5 dBm
- 802.11n: 12.5 ± 1.5 dBm
- Receive Sensitivity:
- 802.11b: -85 dBm (typical) @ 11 Mbps
- 802.11g: -70 dBm (typical) @ 54 Mbps
- 802.11n HT20: -68 dBm (typical) @ MCS15
- 802.11n HT40: -65 dBm (typical) @ MCS15
- Antenna Gain:
- 802.11b/g/n: Right antenna 3.60 dBi, Left antenna 2.51 dBi
- Mechanical:
- USB Storage: Maximum supported capacity: 1 x 2 TB
- Dimensions: 202 x 34 x 160 mm (8.0” x 1.3” x 6.3”)
- Weight: 335 g (11.8 oz)
- Power: 12 VDC, 1.5 A
- Certification: FCC, CE, Telepermit, K.21, UL, CB, Wi-Fi (802.11b/g), WPA™, WPA2™, WMM, Wi-Fi Protected Setup™
- Operating Temperature: 0 to 40°C (32 to 104°F)
- Storage Temperature: -20 to 70°C (-4 to 158°F)
- Operating Humidity: 10 to 85% Noncondensing
- Storage Humidity: 5 to 90% Noncondensing
Connectivity Simplified: Linksys X3000 – Your Gateway to High-Speed, Secure Networking. Upgrade Today!
